外形尺寸
功率 Power(W): 60W
安裝螺釘 Fixing Bolt: M6×85
凈重 N.W.(kg): 4.1
| 電機性能參數 | |||||||||
|
型號 Type |
功率 Power (W) |
電壓 Voltage (V) |
頻率 Frequency (Hz) |
電流 Current (A) |
起動轉矩 Starting Torue mN.m(g.cm) |
額定轉矩 Rated Speed mN.m(g.cm) |
額定轉速 Rated Speed r/min |
電容 Capacitor μF/VAC |
工作狀態 Operating Mode |
| YYTCJ-60-4/90--1 | 60 | 220 | 50 | 0.55 | 350(3500) | 430(4350) | 1350 | 4/450 | 連續 Cont |
| YYTCJ-60-4/90--2 | 0.65 | 430(4300) | 430(4350) | 1350 | 4450 | 30min | |||
| YYTCJ-60-4/90--3 | 60 | 110 | 60 | 1.1 | 220(2200) | 355(3550) | 1650 | 20/450 | 連續 Cont |
| YYTCJ-60-4/90--4 | 1.3 | 260(2600) | 355(3550) | 1650 | 20/450 | 30min | |||
|
允許負載 50Hz |
||||||||||||||||||||||
|
型號 YYTCJ-60-4/90 |
轉速 r/min 速比 |
500 | 416 | 300 | 250 | 200 | 166 | 120 | 100 | 83 | 60 | 50 | 41 | 30 | 25 | 20 | 16 | 15 | 12.5 | 10 | 8.3 | 6 |
| 3 | 3.6 | 5 | 6 | 7.5 | 9 | 12.5 | 15 | 18 | 25 | 30 | 36 | 50 | 60 | 75 | 90 | 100 | 120 | 150 | 180 | 250 | ||
|
轉矩 |
1 | 1.2 | 1.66 | 1.99 | 2.49 | 3.00 | 4.15 | 4.93 | 5.91 | 7.48 | 8.98 | 10.8 | 13.5 | 16.2 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 10 | 12 | 16.6 | 19.9 | 24.9 | 30.0 | 41.5 | 49.3 | 59.1 | 74.8 | 89.8 | 108 | 135 | 162 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | ||
|
允許負載 60Hz |
||||||||||||||||||||||
|
型號 YYTCJ-60-4/90 |
轉速 r/min 速比 |
600 | 500 | 360 | 300 | 240 | 200 | 144 | 120 | 100 | 72 | 60 | 50 | 36 | 30 | 24 | 20 | 18 | 15 | 12 | 10 | 7.2 |
| 3 | 3.6 | 5 | 6 | 7.5 | 9 | 12.5 | 15 | 18 | 25 | 30 | 36 | 50 | 60 | 75 | 90 | 100 | 120 | 150 | 180 | 250 | ||
|
轉矩 |
0.9 | 1.1 | 1.5 | 1.9 | 2.3 | 2.8 | 3.8 | 4.2 | 5.0 | 6.9 | 8.3 | 9.9 | 12.5 | 15 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 9 | 11 | 15 | 19 | 23 | 28 | 38 | 42 | 50 | 69 | 83 | 99 | 125 | 15 | 200 | 200 | 200 | 200 | 200 | 200 | 200 | ||
外形尺寸
